Evacuable Pellet Dies

Evacuable Pellet Dies

REFLEX Analytical offers the largest selection of evacuable pellet dies. Standard sizes range from 3 - 60mm diameter and are used routinely for IR, XRF and XRD powdered sample preparation. Larger diameter, customized geometries and dimensions are encouraged and available upon request for evacuable and non-evacuable type dies.

The dies are commonly used with our series of laboratory presses. Each die is precision manufactured from hardened 440C stainless steel and includes a main body with a vacuum attachment, base, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions. Scroll below and order from the list of standard evacuable circular pellet die sizes.

Optional Tungsten Carbide anvils are available upon request. Tungsten carbide anvils are ideal for hard or abrasive powdered sample materials which may tend to mar the surface of stainless steel anvils. An oil-less vacuum pump is recommended to assist with the production of moisture free pellets.

CLICK HERE to preview other solid and semi-solid sampling accessories such as non-standard size evacuable pellet dies, pellet molds, XRF dies, square and rectangular dies, heated dies, manual and auto lab presses, polymer film makers, and much more.

3mm Evacuable Pellet Die

3mm Evacuable Pellet Die

Part Number: 3055

Precision manufactured from hardened 440C stainless steel and includes a main body with a vacuum attachment, (2) polished stepped anvils, (2) vacuum o-rings, center-aligned die holder with 2" (w) x 3" (l) backplate, stainless steel funnel, pellet extractor and operating instructions.

Assembled Die Height With Stepped Anvils Without Sample Matrix: 37mm

Maximum Pellet Thickness: 3mm

Maximum Load: 0.50 Ton

Features

- simple three piece assembly

- stainless steel funnel is supplied for easy loading of sample matrix into die chamber

- pellet is formed in the die body then placed on the center-aligned die holder for analysis

- pellet can be removed for storage with use of the pellet extractor

Tip

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,395.00

5mm Evacuable Pellet Die

5mm Evacuable Pellet Die

Part Number: 3060

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 2 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,395.00

6mm Evacuable Pellet Die

6mm Evacuable Pellet Die

Part Number: 3070

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 2 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,395.00

8mm Evacuable Pellet Die

8mm Evacuable Pellet Die

Part Number: 3090

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 5 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,395.00

10mm Evacuable Pellet Die

10mm Evacuable Pellet Die

Part Number: 3100

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 7 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,395.00

13mm Evacuable Pellet Die

13mm Evacuable Pellet Die

Part Number: 3000

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 10 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$795.00

16mm Evacuable Pellet Die

16mm Evacuable Pellet Die

Part Number: 3120

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 31mm

Each Die Anvil Thickness: 5.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 14mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 19.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 15 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,695.00

20mm Evacuable Pellet Die Part No. 3165

20mm Evacuable Pellet Die

Part Number: 3165

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 24 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,895.00

25mm Evacuable Pellet Die Part No. 3170

25mm Evacuable Pellet Die

Part Number: 3170

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$1,995.00

32mm Evacuable Pellet Die

32mm Evacuable Pellet Die

Part Number: 3300

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$2,095.00

35mm Evacuable Pellet Die

35mm Evacuable Pellet Die

Part Number: 3350

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$2,895.00

40mm Evacuable Pellet Die

40mm Evacuable Pellet Die

Part Number: 3290

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$3,295.00

XRF Conversion Die Kit Complete

XRF Conversion Die Kit Complete

Includes: 40mm Evacuable Die with 20mm, 25mm and 32mm Conversion Die Kits.

Part Number: 3400

Precision manufactured from hardened 440C stainless steel and includes a main 40mm die body, a removable base with a vacuum attachment, 20mm, 25mm and 32mm conversion die kits, each die size with (2) polished anvils, plunger, vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

CLICK HERE for more information.

$7,395.00

45mm Evacuable Pellet Die

45mm Evacuable Pellet Die

Part Number: 4047

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$3,895.00

50mm Evacuable Pellet Die

50mm Evacuable Pellet Die

Part Number: 4345

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Die Chamber Height Without Sample: 48mm

Each Die Anvil Thickness: 9.50mm

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using Two Anvils: 23mm (accounts for locating die plunger 6mm into die chamber)

Maximum Height In Die Chamber For Uncompressed Sample Matrix Using One Anvil: 32.50mm (accounts for locating die plunger 6mm into die chamber)

Maximum Load: 30 Tons

Tips

- typically the sample pellet is fabricated between two anvils although one anvil can be used to fabricate a thicker sample pellet.

- allow 6mm minimum to locate the die plunger into the die chamber in order to follow the die chamber wall.

- the evacuable design feature with the use of an oil-less vacuum pump permits easy installation of anvils and plunger without the vacuum resistance normally associated with non-evacuable dies due to the precision fabrication and tight tolerances to mitigate flashing of the powdered sample matrix during pellet fabrication.

Operating Instructions CLICK HERE

$6,395.00

55mm Evacuable Pellet Die

55mm Evacuable Pellet Die

Request For Quotation

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

60mm Evacuable Pellet Die

60mm Evacuable Pellet Die

Request For Quotation

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.

Custom Size Evacuable Pellet Die

Custom Size Evacuable Pellet Die

Request For Quotation

Precision manufactured from hardened 440C stainless steel and includes a main body, a removable base with a vacuum attachment, (2) polished anvils, plunger, (2) vacuum o-rings, extractor ring and operating instructions.
